| Items | CBS90Q | CBS120Q | CBS180Q | CBS240Q | |
| Nominal Production Capacity (m3/h) | 90 | 120 | 180 | 240 | |
| Dry filling Capacity(L) | 1500 | 2000 | 3000 | 4000 | |
| Mixer Capacity (m3) | 1.5 | 2 | 3 | 4 | |
| Mixing cycle time/batch(s) | 60 | 60 | 60 | 60 | |
| Mixer Power (kW) | 2x30 | 2x37 | 2x55 | 2x75 | |
| Max. Aggregate Size (mm) | 80 | 80 | 80 | 80 | |
| Cold Feeder Bin (m3) | 3x15 | 4x20 | 4x25 | 4x30 | |
| Aggregate Batching Capacity (L) | 2400 | 3200 | 4800 | 6400 | |
| Belt Conveyor Width(mm) | 800/1000 | 800/1000 | 800/1000 | 1200 | |
| Screw Conveyor Capacity (t/h) | 2x80+2x100 | 2x80+2x100 | 2x80+2x100 | 4x100 | |
| Discharging Height (m) | 4.2 | 4.2 | 4.2 | 4.2 | |
| Installed Power (kW) | 155 | 215 | 280 | 349 | |
| Full Scale Range(kg) & Accuracy | Aggregates | 2000±1% | 2000±1% | 3000±1% | 4000±1% |
| Cement | 800±1% | 1200±1% | 1800±1% | 2400±1% | |
| Fly ash | 400±1% | 600±1% | 800±1% | 1000±1% | |
| Water | 500±1% | 600±1% | 800±1% | 1000±1% | |
| Additives | 30±1% | 30±1% | 50±1% | 50±1% | |
