| Items | CBS90Q | |
| Nominal Production Capacity (m3/h) | 90 | |
| Dry filling Capacity(L) | 1500 | |
| Mixer Capacity (m3) | 1.5 | |
| Mixing cycle time/batch(s) | 60 | |
| Mixer Power (kW) | 2x30 | |
| Max. Aggregate Size (mm) | 80 | |
| Cold Feeder Bin (m3) | 3x15 | |
| Aggregate Batching Capacity (L) | 2400 | |
| Belt Conveyor Width(mm) | 800/1000 | |
| Screw Conveyor Capacity (t/h) | 2x80+2x100 | |
| Discharging Height (m) | 4.2 | |
| Installed Power (kW) | 155 | |
| Full Scale Range(kg) & Accuracy | Aggregates | 2000±1% |
| Cement | 800±1% | |
| Fly ash | 400±1% | |
| Water | 500±1% | |
| Additives | 30±1% | |
| Items | CBS120Q | |
| Nominal Production Capacity (m3/h) | 120 | |
| Dry filling Capacity(L) | 2000 | |
| Mixer Capacity (m3) | 2 | |
| Mixing cycle time/batch(s) | 60 | |
| Mixer Power (kW) | 2x37 | |
| Max. Aggregate Size (mm) | 80 | |
| Cold Feeder Bin (m3) | 4x20 | |
| Aggregate Batching Capacity (L) | 3200 | |
| Belt Conveyor Width(mm) | 800/1000 | |
| Screw Conveyor Capacity (t/h) | 2x80+2x100 | |
| Discharging Height (m) | 4.2 | |
| Installed Power (kW) | 215 | |
| Full Scale Range(kg) & Accuracy | Aggregates | 2000±1% |
| Cement | 1200±1% | |
| Flyash | 600±1% | |
| Water | 600±1% | |
| Additives | 30±1% | |
| Items | CBS180Q | |
| Nominal Production Capacity (m3/h) | 180 | |
| Dry filling Capacity(L) | 3000 | |
| Mixer Capacity (m3) | 3 | |
| Mixing cycle time/batch(s) | 60 | |
| Mixer Power (kW) | 2x55 | |
| Max. Aggregate Size (mm) | 80 | |
| Cold Feeder Bin (m3) | 4x25 | |
| Aggregate Batching Capacity (L) | 4800 | |
| Belt Conveyor width(mm) | 800/1000 | |
| Screw Conveyor Capacity (t/h) | 2x80+2x100 | |
| Discharging Height (m) | 4.2 | |
| Installed Power (kW) | 280 | |
| Full Scale Range(kg) & Accuracy | Aggregates | 3000±1% |
| Cement | 1800±1% | |
| Flyash | 800±1% | |
| Water | 800±1% | |
| Admixture | 50±1% | |
| Items | CBS240Q | |
| Nominal Production Capacity (m3/h) | 240 | |
| Dry filling Capacity(L) | 4000 | |
| Mixer Capacity (m3) | 4 | |
| Mixing cycle time/batch(s) | 60 | |
| Mixer Power (kW) | 2x75 | |
| Max. Aggregate Size (mm) | 80 | |
| Cold Feeder Bin (m3) | 4x30 | |
| Aggregate Batching Capacity (L) | 6400 | |
| Belt Conveyor Width(mm) | 1200 | |
| Screw Conveyor Capacity(t/h) | 4x100 | |
| Discharging Height (m) | 4.2 | |
| Installed Power (kW) | 349 | |
| Full Scale Range(kg) & Accuracy | Aggregates | 4000±1% |
| Cement | 2400±1% | |
| Fly ash | 1000±1% | |
| Water | 1000±1% | |
| Admixture | 50±1% | |
