| Model | DGMB 1000 | DGMB 1500 | DGMB 2000 |
| Capacity (Moisture Content≤5%） | 60~100tph | 100~150tph | 150~200tph |
| Cold Feeder Qty. | 4 | 4 | 5 |
| Dryer Drum | φ1.6×8.0m | φ1.9×8.5m | φ2.2×9.0m |
| Burner | Diesel/Fuel Oil/Natural Gas /Coal | ||
| Dust Collector | 390㎡ | 500㎡ | 640㎡ |
| Mixer | External Continuous Mixer | ||
| Aggregate Scale | Continuous Belt Scale | ||
| Filler Scale | Continuous Subtractive Filler Scale | ||
| Bitumen Scale | Continuous Flow Bitumen Scale, Forced Uniform Multi-point Spray | ||
| Recycling Ring | Optional. Max. RAP Addition Ratio: 35%. | ||
| Filler Silo | 10m³ | 10m³ | 15m³ |
| Warm-mix System | Optional | ||
